FEATURES
Tuner
- Memory Presets: Preset Stations (FM:18 / MW:6 / LW:6)
- Memory: Auto Memory
- Seek Mode: Local / DX Selection / Manual
RDS
- RDS Functions: TA, TP, RADIO TEXT, RDS EON, PTY 31
Bluetooth®
- Parrot Bluetooth Ready
- Connection : Alpine KCE-400BT/-250BT Required. Features may differ between phone models and service providers.
- Hands Free : Hands Free Calling
- Phone Book : Phone Book Transfer
- Voice Dial (with KCE-400BT or KCE-250BT)
- Streaming Music : Streaming Music Playback (Only KCE-400BT)
- Streaming Music Control : Streaming Music Control (Only KCE-400BT)
Connection for iPod®
- Made for iPod/iPhone:
- USB Connection (original white iPod USB cable)
- M.I.X. (Shuffle) Capability: Song, Albums, All
- Music Control: Song Up / Down / Repeat
- Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook
- Percentage Search (Direct Search Function)
- Information Display: Artist, Song, Album
- Quick Search & Direct iPod Control
Disc Player
- Type: CD Player
- Disc Playback Type: CD/CD-R/CD-RW
- Music Playback: MP3/AAC/WMA Playback
- 1Bit DAC
- Zero Data Mute
- Digital Servo
- Music Sensor Scan/Repeat
- Playback Control: Play/Pause/Forward/Backward
- M.I.X. Mode: One (Folder)/All (Random Play)/Random (CD Only)
- Quick Search
USB Media Connection
- 2x USB Connection: Front Panel Slot & Rear Connection
- MP3/AAC/WMA Playback
- 1.5m USB Extension Cable Included
Sound Tuning
- 3-Bands Parametric EQ
- Subwoofer Level Adjustment
- High Pass Filter Adjustment / Low Pass Filter Adjustment
- Bass Level Adjustment
- Bass Center Frequency Adjustment
- Bass Bandwidth Adjustment
- Mid Level Adjustment
- Mid Center Frequency Adjustment
- Mid Bandwidth Adjustment
- Treble Bandwidth Adjustment
- Treble Level Adjustment
- Treble Center Frequency Adjustment
- Loudness
- Source Tone Memory
General
- 4 x 50 W High Power Amplifier
- 14 Segment White LCD Display
- Control Type: Rotary Encoder Knob
- Face Color: Black
- 4 Illumination Colours Selectable (Blue/Green/Red/Amber)
- 3 PreOuts (2V, Front/Rear/Subwoofer Selectable)
- Front AUX Input (3.5 mm mini jack)
- 2x USB Input (Front and Rear)
- Steering Wheel Remote Control Ready
- Bass, Mid & Treble Controls
- Fader & Balance Controls
- Detachable Trim Plate
- Detachable Face Plate
- Dimmer Input
- Power Antenna Output
- Amplifier Remote Control Output
- Audio Interrupt Input
SPECIFICATIONS
Max Power Output Ratings
- Max Power Output: 4 x 50 W
FM Tuner
- Tuning Range: 87.5-108.0 MHz
- Mono Usable Sensitivity: 0.7 µV
- Alternate Channel Selectivity: 80.0 dB
- Signal-to-Noise (S/N) Ratio: 65.0 dB
- Stereo Separation: 35.0 dB
- Capture Ratio: 2.0 dB
MW Tuner
- Tuning Range: 531-1,602 kHz
- Usable Sensitivity (IEC Standard): 25.1/28.0 (µV/dB)
LW Tuner
- Tuning Range: 153-281kHz
- Usable Sensitivity (IEC Standard): 31.6/30.0 (µV/dB)
Connection for USB
- USB Requirements: 1.1/2.0
- Max. Power Consumption: 500 mA
- USB Class: Mass Storage
- File System: FAT 12/16/32
- MP3 Decoding: MPEG-1/2 AUDIO Layer-3
- Number of Channels: 2-Channel (Stereo)
- Frequency Response: 5-20 k ±1 dB (Frequency Response may differ depending on the encoder software/bit rate)
- Total Harmonic Distortion: 0.008% (at 1 kHz)
- Dynamic Range: 95 dB (at 1 kHz)
- Signal-to-Noise Ratio: 105 dB
- Channel Separation: 85 dB (at 1 kHz)
Disc Player
- Frequency Response: 5-20 kHz ±1 dB
- Channel Separation (1 kHz): 85 dB
- Dynamic Range (1kHz): 95 dB
- Total Harmonic Distortion (THD): 0.008% (at 1 kHz)
- Wow & Flutter (%WRMS): B.M.L.
- Audio Signal-to-Noise (S/N): 105 dB
Sound Tuning
- Subwoofer Level Adjustment: 0 to 15
- High Pass Filter: OFF/60/80/120/160 Hz (Selectable)
- Low Pass Filter: OFF/60/80/120/160 Hz (Selectable)
- Bass Level Control Range: -7 to +7
- Bass Center Frequency: 60/80/100/120 Hz (Selectable)
- Bass Band Width Adjustment (Q): 4 choices (0,5=wide, 1/1,5=medium, 2=narrow)
- Mid Level Control Range: -7 to +7
- Mid Center Frequency: 500/1k/1,5k/2,5k Hz (Selectable)
- Mid Band Width Adjustment (Q): 4 choices (0,75=wide, 1/1,25=medium, 1,5=narrow)
- Treble Level Control Range: -7 to +7
- Treble Center Frequency: 7,5/10/12.5/15kHz (Selectable)
- Treble Band Width Adjustment (Q): 2 choices (0,75=wide, 1,25=narrow)
- Subwoofer Phase Selection (0°/180°)
- 10 Factory EQ Presets
Dimensions
- Din Size: 1
- Chassis Size (W x H x D) mm: 178 mm x 50 mm x 161 mm
- Nose Piece Size (W x H x D) mm: 170 mm x 46 mm x 25 mm
General
- Power Requirement: 14.4 (11-16) V.DC
- Pre Output Voltage (Before Clipping): 2 V
- Operating Temperature (°C): -10°C to +60°C
- Maximum Mounting Angle: 35° from Horizontal
- Weight: 1.5 kg
-
Size:1-DIN
-
USB:Front and Rear
-
Key Illumination:Variable colour
-
PreOuts:3
-
AUX-in:Front
-
SWRC ready:Yes
