FEATURES
Tuner
- Memory Presets: Preset Stations (FM:18 / MW:6 / LW:6)
- Memory: Auto Memory
- Seek Mode: Local / DX Selection / Manuell
RDS
- RDS Functions: AF, TA, TP, PTY, NEWS, RADIO TEXT
Bluetooth®
- Priority Setting for Navigation Voice Guidance
- Built-In Parrot Bluetooth Module
- Bluetooth menu in 6 languages
- Hands Free Calling
- Phone Book Transfer
- Phone Book Search: Alphabet Skip Function and Initial Letter Search
- Five Quick Dial Key Memory
- Wired Microphone Included
- Redial Function
- Call History Display
- Adjusting the volume when receiving a call:
- Voice Dial Operation
Connection for iPod®
- Made for iPod/iPhone
- USB Connection (USB Cable Included)
- Compatibility for iPod®: iPod touch 4G/3G/2G/1G, iPod classic, iPod with Video, iPod nano 6G/5G/4G/3G/2G/1G, iPhone 4, iPhone 3GS, iPhone 3G, iPhone
- M.I.X. (Shuffle) Capability: Song, Albums, All
- Music Control: Song Up/Down, Fast Forward/Backward, Repeat
- Video Playback
- Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook
- Percentage Search Function
- Alphabet Search Function
- Information Display: Album Art, Song (Title, Album)
- Direct iPod/iPhone Control Function
Disc Player
- DVD/CD Player
- Disc Playback Type: DVD Video, DVD Audio (2ch mix down), CD, CD-R, CD-RW, DVD±R/±RW, DVD-VR
- Compressed Media Playback: DivX/MP3/WMA/AAC Playback
- 24bit-DAC
- Zero Data Mute
- Digital Servo
- Sensor: Music Sensor Scan, Repeat
- Playback Control: Play/Pause, Fast Forward/Backward
- DVD Direct Menu Control
- M.I.X. Mode: One (Folder) / All (Random Play) / Random (CD Only)
USB Media Connection
- USB Connection (USB Cable Included)
- Cover Art Display
- Music Playback: MP3/AAC/WMA Playback
- USB Class: Mass Storage, Play from device
- Works with Nokia
- Banking: Max. 20 Banks (20,000 songs)
- Disengageable Banking Feature
- MTP Ready: Search music by Album, Artist, Song, Playlist, Genre, Composer, Folder, File
Sound Tuning
- Subwoofer Level Adjustment
- Subwoofer Phase Select
- Subwoofer System Select
- High Pass Filter Adjustment
- Bass Level Adjustment
- Bass Center Frequency Adjustment
- Bass Bandwidth Adjustment
- Treble Level Adjustment
- Treble Center Frequency Adjustment
- Source Tone Memory
- MediaXpander
- Time Correction Adjustment
- Equalizer: 7-Band Graphic or 5-Band Parametric Equalizer Feature
CD/DVD Changer Control
- M.I.X.: One/All (Shuffle)
- Multi-Changer Control
- Music Text Information: CD: Text Scroll Display, MP3: Text Information (ID3 Tag)
- Music Control: Play/Pause, Fast Forward/Backward
- Repeat: Song, Disc
General
- Power Output: 4 x 50 W High Power Amplifier
- Display: 7′′ WVGA Touch Screen Display
- Illumination Buttons: White Illuminated Buttons
- Digital Signal Output
- High Grade Audiophile Design:
- SD Card: Video Playback
- PreOut: 3 PreOuts (4V) and 1 AV Output
- PreIn: 2 PreIn (Front / Rear) Ready
- AUX-In: 1 AV Input
- Steering Wheel Control Ready (Adapter Required)
- Auto Dimmer
- Power Antenna Output
- Amplifier Remote Turn-On Output
- Audio Interrupt
- Remote Control Included
- Camera Input Select OFF/Direct/RCA
- Camera System Select: Frontview Camera, Rearview Camera, Topview Camera
- Camera View Angle Select: Rearview, Panorama view, Corner view, Ground view
- Camera Guide Line Adjustment
- Dual Zone Control
- Visual EQ: OFF/Night M./Soft/Sharp/Contrast/P-1/P-2
- Security Code Anti-theft
SPECIFICATIONS
Max Power Output Ratings
- Max Power Output: 4 x 50 W
FM Tuner
- Tuning Range: 87.5-108.0 MHz
- Mono Usable Sensitivity: 8.1 dBf (0.7 µV / 75 ohms)
- Alternate Channel Selectivity: 80.0 dB
- Signal-to-Noise (S/N) Ratio: 65.0 dB
- Stereo Separation: 35.0 dB
- Capture Ratio: 2.0 dB
MW Tuner
- Tuning Range: 531-1,602 kHz
- Usable Sensitivity (IEC Standard): 25.1/28.0 (µV/dBf)
LW Tuner
- Tuning Range: 153-281 kHz
- Usable Sensitivity (IEC Standard): 31.6/30.0 (µV/dBf)
Navigation
- Received Frequency: 1.57542 ±1.023MHz
- Receiving Sensitivity: -130 dBm
Bluetooth®
- Bluetooth Version: Bluetooth V2.0
- Output Power: +4 dBm Max. (Power class 2)
- HFP (Hands Free Profile)
- HSP (Head Set Profile)
Connection for USB
- USB Requirements: USB 1.1/2.0
- Max. Power Consumption: 500 mA
- USB Class: Mass Storage, Play from device
- File System: FAT 12/16/32
- MP3 Decoding: MPEG-1/2 AUDIO Layer-3
- WMA Decoding: Windows Media™ Audio
- AAC Decoding: ACC-LC format ′′/m4a′′ file
- Number of Channels: 2-Channel (Stereo)
- Frequency Response: 5-20 kHz ±1 dB (Frequency Response may differ depending on the encoder software/bit rate)
- Total Harmonic Distortion: 0.008% (at 1 kHz)
- Dynamic Range: 95 dB (at 1 kHz)
- Signal-to-Noise Ratio: 105 dB
- Channel Separation: 85 dB (at 1 kHz)
Disc Player
- Frequency Response: 5Hz -20kHz ±1 dB
- Channel Separation (1kHz): 85 dB
- Dynamic Range (1kHz): 95 dB
- Total Harmonic Distortion (THD): 0.008% (at 1 kHz)
- Wow & Flutter (%WRMS): B.M.L.
- Audio Signal-to-Noise (S/N): 105 dB
- Horizontal Resolution: 500 lines or greater
- Video Output Level: 1 Vp-p (75 ohms)
- Video Signal-to-Noise (S/N): DVD: 60 dB
Sound Tuning
- Subwoofer Level Adjustment: 0 to 15
- High Pass Filter: OFF/60/80/100Hz (Selectable)
- Bass Level Control Range: -6 to +6
- Bass Center Frequency: 63/80/100Hz (Selectable)
- Bass Bandwidth Adjustment (Q): 4 choices (1 =narrow, 4 =wide)
- Treble Level Control Range: -6 to +6
- Treble Center Frequency: 10/12.5/16/17.5kHz (Selectable)
- Time Correction: 0.0 - 9.9 ms (0.1ms)
- Parametric Equalizer: 5-Band, 63Hz - 17.5KHz (1/3 oct. steps), Adjustable level -6 to +6 dB, Adjustable Bandwidth 1/2/3/4
- Graphic Equalizer: 7-Band (80, 250, 500, 1k, 4k, 8k, 16kHz), Adjustable Output Level -6 to +6dB
Remote Control
- Included/Ready: Included
- Model Number: RUE-4203
- Battery Type: CR2025 (1pce)
- Dimension (W x H x D) mm: 51mm x 119mm x 13mm
- Weight: 40g
Map & Database
- Online Update Method: visit www.naviextras.com
Dimensions
- Din Size: 2 DIN
- Chassis Size (W x H x D) mm: 178mm x 100mm x 163.6mm
General
- Power Requirement: 14.4 (11-16) V.DC
- Screen Size: 7 inch Wide VGA Screen
- Number of Picture Elements: 1,152,000 pixels
- Effective Number of Pixels: 99.99% or more
- Illumination System: LED
- Pre Output Voltage (Before Clipping): 4 V
- Operating Temperature (°C): 0°C - +45°C
- Maximum Mounting Angle: 30° from Horizontal
- Weight: 2.7kg
-
Size:2-DIN
-
Screen size:7"
-
Bluetooth:Built-in
-
Key Illumination:White
-
PreOuts:3 (4V)
-
iPhone/iPod:Direct control
-
Remote control:IR included
-
Inputs:USB
Audio/Video
Camera
-
SWRC ready:Yes
