General
(SPK Connect)
4Layer Glass Epoxy PC Board
Class-D
Layered Installation
1/2 Channel Operation
Thermal Management Processor
Adjustable Crossover (HP/LP)
MOSFET Power Supply
DC-DC PWM Power Supply
MOSFET Final Outputs
STAR Circuitry
Auto Over-Current Protection
Top Mounted Blue LED Power/Status Indicator
Integrated Wire and Mounting Screw Terminals
One Side Terminal Layout
Gold Plated RCA Input Connectors
Continuously Adjustable Gain Control
Gold Plated Power Screw Terminals
Dimensions: 257mm x 192mm x 62mm
RMS Power
[2ohms @14.4V 1%THD]: 150W x 2
[4ohms @14.4V 1%THD]: 150W x 2
Bass Engine® Sound Tuning
Crossover Frequency Adjustment:
30Hz - 400Hz HP/LP/Off (-12dB/oc
-
Maximum Output Power:150 W
-
RMS Power per channel at 2 ohm:150 W
-
RMS Power per channel at 4 ohm:150
-
Built-in filters:
-
Minimum Impedance:2 Ohm Ohm
-
Amplifier Class:Class D
