FEATURES
Gasket
- Design: Rubber Mounting Gasket
Tinsel Leads
- Design: 16ga. Stranded Leads, Insulated
Terminals
- Design: 2-Way, Insert & Quick-Connect Terminals
- Layout: One Side
Frame
- Design: Custom High Strength 5-Leg
- Material: Injection Molded Polypropylene
Motor Structure
- Configuration: Airflow Management System
- Pole Geometry: Compound Radius Curve
Voice Coil
- Design: 4-Layer Single Voice Coil
- Material: High Temp. Copper Wire on TIL Former
Spider
- Design: Progressive
- Material: Nomex®
Surround
- Design: High Amplitude Multi-Roll
- Material: Injection Molded Sanoprene®
Diaphram
- Design: 2-Piece Structural Parabolic
- Material: Molded Polypropylene
SPECIFICATIONS
Dimensions
- Added Volume: 0.055 cu. ft. (Reverse Mount, Magnet Out)
- Displacement: 0.083ft cu. ft. (Front Mount)
- Mounting Diameter: 229 mm (9-1/32'')
- Mounting Depth: 144.72 mm (5-11/16'')
Power Handling
- Peak Power Handling: 900 Watts
- RMS Power Handling: 300 Watts
- CEA-2006 Power Rating: 300 Watts
-
Max. Power:900 W
-
RMS Power:300 W
-
Sensitivity:86 dB/W/m
-
Mounting Depth:144.72 mm
